JHAC J-Hook Cable Support with 90° Angle Clip - 1/4" hole by Doc's Industries Inc.

The JHAC J-Hook Cable Support is a galvanized steel pathway component supplied by Hook and Hanger for datacom and low-voltage work. Each unit has a yellow zinc chromate finish and a patented 90° angle clip that gives installers a direct attachment point for cabling routes. It supports dependable cable management where overhead space and code alignment matter.

Hook and Hanger stocks this hardware for crews that need a heavy-duty structural anchor for data comm and low-voltage cables, including CAT 5e, CAT 6, and fiber optics. This component is cULus listed, NEC/TIA compliant for structured cabling systems, and Plenum-rated for air-handling spaces.

What Is the JHAC J-Hook Cable Support with 90° Angle Clip Used For?

This hardware creates a controlled overhead route for communication cables without crushing, kinking, or loosely draping the bundle. We supply it for datacom crews working in offices, schools, warehouses, and interiors.

• Supports high-speed data lines, CAT 5e, CAT 6, and fiber optic pathways in structured cabling systems.

• Uses an integrated 90° angle clip with a 1/4" hole for attachment to approved surfaces.

• Helps crews maintain cable separation, route organization, and accessible pathway changes above a suspended ceiling.

• Works with other support hardware when field conditions require purlin clips, surface fastening, or alternate attachment methods.

What Are the JHAC J-Hook Cable Support Specifications?

The JHAC J-Hook Cable Support is available in four structural sizing options so the installer can match hook diameter to cable volume. Hook and Hanger supplies these parts in 100-piece box packaging for staging and nationwide distribution.

• Material: galvanized steel with yellow zinc chromate finish.

• Design: patented J-hook support with integrated 90° angle clip and 1/4" mounting hole.

• Compliance: UL listed, cULus listed, NEC/TIA compliant, and Plenum-rated.

• JH-12AC: 3/4" Size | Load Capacity: 17 lbs. | Support Capacity: 16 CAT 5e / 2-strand fiber optic, or 10 CAT 6.

• JH-21AC: 1 5/16" Size | Load Capacity: 17 lbs. | Support Capacity: 50 CAT 5e / 2-strand fiber optic, or 32 CAT 6.

• JH-32AC: 2" Size | Load Capacity: 17 lbs. | Support Capacity: 80 CAT 5e / 2-strand fiber optic, or 50 CAT 6.

• JH-64AC: 4" Size | Load Capacity: 50 lbs. | Support Capacity: 300 CAT 5e / 2-strand fiber optic, or 185 CAT 6.

How Does the JHAC J-Hook with 90° Angle Clip Attach to Overhead Structure?

The patented 90° angle clip is the structural interface on the JHAC J-Hook Cable Support. Its 1/4" hole gives the installer a defined fastening point for mounting to a suitable overhead structure, based on the approved substrate, engineering requirements, and fastening method. This helps crews place the hook in a controlled position instead of routing cable around framing, deck conditions, or existing services.

For installers evaluating the part alongside overhead drilling and anchoring operations, the clip provides a stable mount for planning hole location, fastener selection, and cable pathway direction. The hook body carries the bundle below the attachment point, helping maintain bend radius and service access.

Hook and Hanger also supports projects where this hardware must coordinate with beam clamps, angle clips, and other fastening parts. In complex commercial environments, the attachment method may change where steel beams, concrete decking, ceiling grids, and mechanical systems compete for overhead space. A consistent support component keeps the pathway organized while matching the mount to the structure.

Why Use JHAC J-Hook Galvanized Steel Supports in Plenum Spaces?

Plenum spaces require careful hardware selection because the ceiling cavity may function as part of the air-handling pathway. The JHAC J-Hook Cable Support is plenum-rated, helping contractors specify a metal pathway component for these interior conditions. Its galvanized steel body and yellow zinc chromate finish give the part a rigid profile for repeated commercial installation work.

NEC and TIA compliance matter because structured cabling is not only a routing task. It must be supported in a way that protects cable performance, reduces strain, and preserves a maintainable pathway. This product helps installers keep low-voltage cabling off ceiling tile, away from unapproved supports, and positioned for inspection and service access.

We offer this product for contractors who want a direct support solution without shifting between unrelated hardware during the same run. Hook and Hanger also supplies j-hooks, extension poles, eye lag screws, and threaded rod fasteners when the project requires mixed attachment points. This gives foremen and purchasing teams a practical way to match the support method to the structure, cable load, and installation sequence.

Order JHAC J-Hook Cable Supports From Hook and Hanger

Choosing Hook and Hanger means equipping your construction crews with dependable, code-compliant overhead support parts designed to perform on demanding jobsites. By integrating the exact engineering, high-tensile structure, and advanced material compatibility of this specific support system into your project plans, you secure an efficient, hassle-free installation backed by a specialist team focused entirely on practical hardware solutions.

To purchase your JHAC J-Hook Cable Support inventory or to explore our complete selection of alternative purlin clips, beam clamps, eye lag screws, and threaded rod fasteners, visit hookandhanger.com today. For technical support, bulk pricing tiers, or submittal documentation, call our specialist team at 805-583-9920 or email info@hookandhanger.com.
