HPHFM58 Series J-Hook - Composite Wide Base Hook with knock-on spring steel beam clamp for flanges 5/16 - 1/2" thick, swivels 360° by Doc's Industries Inc.

The HPHFM58 cable support gives datacom crews a protected overhead pathway for structured cabling while attaching directly to structural steel. It combines a slick, burr-free 2-inch-wide plastic base with a rigid, high-strength metal backbone and a pre-assembled knock-on spring steel beam clamp. Hook and Hanger supplies this hybrid layout for organized cable management in commercial interiors where installers need a smooth cable-contact surface and a direct steel attachment. The components are cULus listed and RoHS and TIA compliant.

The HPHFM58 cable support is designed for Cat 5e, Cat 6, Cat 6A, Cat 7, and fiber optic runs. Its broad plastic base supports bundles across a smooth contact surface, while the heavy-duty flange clip provides a structural anchor on suitable steel. This layout reduces the need to assemble separate hooks, clamps, and retaining materials at ceiling height, supporting consistent pathway installation across long horizontal runs.

What Is the HPHFM58 Cable Support Used For?

This component supports low-voltage communication cabling above finished ceilings and within open commercial interiors. Each HPHFM58 cable support creates an accessible pathway that lets installers place, inspect, and add cables without enclosing the bundle in raceway. It suits network distribution runs where pathway capacity, separation, and service access must be maintained through the installation.

Unlike narrow metal j-hooks that can concentrate contact along a smaller edge, the hybrid base distributes the bundle across a 2-inch-wide plastic surface. The integrated snap-lock retainer latch closes after the cables are placed, replacing loose wire loops, cable ties, or hook-and-loop wraps. Its 3.57-inch average bend radius helps eliminate sharp pathway turns that can strain conductors, deform cable jackets, and contribute to performance loss or signal degradation in high-speed lines. This configuration keeps the pathway open for additions while maintaining positive cable retention.

What Are the HPHFM58 Cable Support Specifications?

Hook and Hanger offers four HPHFM58 cable support sizes to match the pathway diameter to planned bundle volume. Capacities below use a conservative 70% fill rate and include a 3-to-1 safety factor for load tolerances. Verify cable counts, spacing, and structural conditions before installation.

• HPH16FM58: 1.07 in² area; 1-inch diameter; capacity: 20 Cat 5e, 15 Cat 6, 10 Cat 6A; UL load rating: 20 lbs (88.96 N); package quantity: 25; weight: 5 lbs.

• HPH32FM58: 3.97 in² area; 2-inch diameter; capacity: 90 Cat 5e, 60 Cat 6, 35 Cat 6A; UL load rating: 20 lbs (88.96 N); package quantity: 25; weight: 6 lbs.

• HPH48FM58: 9.26 in² area; 3-inch diameter; capacity: 200 Cat 5e, 150 Cat 6, 80 Cat 6A; UL load rating: 20 lbs (88.96 N); package quantity: 25; weight: 11 lbs.

• HPH64FM58: 15.48 in² area; 4-inch diameter; capacity: 330 Cat 5e, 220 Cat 6, 140 Cat 6A; UL load rating: 20 lbs (88.96 N); package quantity: 25; weight: 13 lbs.

How Does the HPHFM58 Cable Support Attach to Structure?

The HPHFM58 cable support uses a metal backbone pre-assembled to a knock-on spring steel beam clamp. It is designed to grip heavier structural flanges measuring 5/16 inch to 1/2 inch thick, providing direct mounting where accessible building steel is available.

• Position the spring steel clamp over a compatible structural steel beam, framework member, or column flange. Confirm that the flange thickness is within the stated 5/16-inch to 1/2-inch range.

• Strike the clamp into position with a hammer so the spring steel grips the flange securely. This eliminates drilling or fastening into the structural member and can reduce reliance on separate overhead drilling and anchoring methods.

• Use the integrated swivel connection to rotate the hook assembly through 360 degrees. This lets the pathway align with branch directions, offsets, and changing route geometry without forcing an abrupt cable turn.

• Review surrounding support methods during layout. Beam clamps, angle clips, and purlin clips are separate attachment approaches for different steel profiles and should be selected only when their stated conditions match the structure.

• Where the work area is above normal reach, crews may use appropriate installation tooling, including extension poles, when the tool, procedure, and site safety controls are suitable for the task.

Why Use Hybrid J-Hooks in Plenum Spaces?

The HPHFM58 cable support is plenum rated for approved air-handling spaces above a suspended ceiling, where pathway materials must meet applicable requirements. The plastic base provides a smooth cable-contact surface, while the metal backbone and spring steel clip provide the structural connection needed to support the stated load. This supports orderly cable routing in spaces that may later require inspection, maintenance, or network expansion.

Color options in white, red, blue, and black can identify cable groups, systems, or pathway assignments across a large installation. Consistent color use can shorten troubleshooting time and make handoff documentation clearer. We stock these support configurations for contractor orders and nationwide distribution, and Hook and Hanger can help purchasing teams align package quantities and color selections with the project takeoff.

Order HPHFM58 Cable Supports From Hook and Hanger

Choosing Hook and Hanger means equipping your construction crews with dependable, code-compliant overhead support parts designed to perform on demanding jobsites. By integrating the exact engineering, high-tensile structure, and advanced hybrid material compatibility of this specific support system into your project plans, you secure an efficient, hassle-free installation backed by a specialist team focused entirely on practical hardware solutions.

To purchase your HPHFM58 cable support inventory or to explore our complete selection of alternative purlin clips, beam clamps, eye lag screws, and threaded rod fasteners, visit hookandhanger.com today. For technical support, bulk-order assistance, or submittal documentation, call our specialist team at 805-583-9920 or email info@hookandhanger.com.
